LZS series pvc acid small pipeline liquid flow meter
1.Material :Taper tube is AS,pipe,screw cap,setting.float is ABS ,leader SS316
2.This flow meter could be made into flange connection type or threaded connection
or glue connection type
3.Working Pressure:≤0.6MPa
4. Temperature:0~60 C
5. Accuracy:±4%
6. Capable of withstanding weak chemicals
7.The materials of float,joint pipe and leader could be customized.
Technical parameters of LZS-series flow meter (glue)
| Model | Diameter | Measure Range | Accuracy | Conditions | Size(mm) | Suit Pipe | |||||||||
| DN mm | Long Tube Type | Short Tube Type | TemperatureºC | Pressure (MPa) | Long Tube Type | Short Tube Type | Dg(mm) | ||||||||
| LZS-15 | 15 | 10-100L/h | 5-50L/h | 4% | 0-60 | ≤0.6 | L | D1 | D2 | D3 | L | D1 | D2 | D3 | 15/20 |
| 16-160L/h | 10-100L/h | 280 | 20 | 26 | 45 | 202 | 20 | 26 | 45 | ||||||
| 25-250L/h | 16-160L/h | ||||||||||||||
| 40-400L/h | 25-250L/h | ||||||||||||||
| 60-600L/h | 40-400L/h | ||||||||||||||
| 60-600L/h | |||||||||||||||
| 100-1000L/h | |||||||||||||||
| LZS-20 | 20 | 60-600L/h | 231 | 25 | 35 | 45 | |||||||||
| 100-1000L/h | |||||||||||||||
| LZS-25 | 25 | 100-1000L/h | 100-1000L/h | 380 | 32 | 39 | 68 | 226 | 32 | 39 | 68 | 25/32 | |||
| 160-1600L/h | 160-1600L/h | ||||||||||||||
| 250-2500L/h | 250-2500L/h | ||||||||||||||
| LZS-32 | 32 | 0.4-4m3/h | 288 | 40 | 49.5 | 74 | 32/40 | ||||||||
| 0.6-6m3/h | |||||||||||||||
| LZS-40 | 40 | 0.4-4m3/h | 430 | 50 | 63 | 88 | 40/50 | ||||||||
| 0.6-6m3/h | |||||||||||||||
| 1-10m3/h | |||||||||||||||
| LZS-50 | 50 | 0.4-4m3/h | 430 | 63 | 73 | 98 | 341 | 63 | 73 | 98 | 50/65 | ||||
| 0.6-6m3/h | 1-10m3/h | ||||||||||||||
| 1-10m3/h | 1.6-16m3/h | ||||||||||||||
| 1.6-16m3/h | |||||||||||||||
| LZS-65 | 65 | 2.5-16m3/h | 430 | 75 | 88 | 122 | 65/75 | ||||||||
| 5-25m3/h | |||||||||||||||
| 8-40m3/h | |||||||||||||||
| 12-60m3/h | |||||||||||||||
